HP DesignJet T630 (5HB11A)

HP DesignJet T630 36-in Printer
id="p3934774"> HP DesignJet T630 36-in PrinterManufacturer HP INC. Manufacturer Part No 5HB11A#B19Marketing DescriptionAt the office or on the job-site, bring your biggest ideas to life from virtually anywhere with the high-quality, easy-to-use plotter. Product Features

• Extreme simplicity
  Print multi-size A3/B and A1/D or A0/E projects automatically, without manually switching the media source. Save time with the world's easiest job submission - send multiple files in one click with HP Click software. Print with confidence you'll get the results you expect with an intuitive driver and true print preview.
• Fits your office and budget
  Save space with the world's smallest plotters designed to fit your office, including a built-in stand. Use up to 95% less ink for routine maintenance and get up to 100 extra A1/D pages per month. More sustainable design reduces CO2e up to 7.3tons/year by units sold by using up to 30%recycled plast

GeneralPrinter Type36" large-format printer - ink-jet - colourLocalisationEnglish, German, French, Italian, Spanish / EuropePrinterInkjet TechnologyHP Thermal InkjetInk Palette Supported (Colours)4-ink - cyan, magenta, yellow, pigment blackNozzle Configuration1376 nozzlesMinimum Ink Droplet Size12 pl (black), 5.5 pl (colour)Ink Cartridge Configuration4 cartridges (1 each: cyan, magenta, yellow, pigment black)Print SpeedUp to 0.5 min/page - black draft - ANSI D (559 x 864 mm)
Up to 0.5 min/page - colour draft - ANSI D (559 x 864 mm)
Up to 0.5 min/page - black draft - A1 (594 x 841 mm)
Up to 0.5 min/page - colour draft - A1 (594 x 841 mm)Connectivity TechnologyWirelessInterfaceUSB 2.0, LAN, Wi-FiMax Resolution (B&W)2400 x 1200 dpiMax Resolution (Colour)2400 x 1200 dpiLanguage SimulationHP RTL, CALS G4, HP GL/2, URF, JPEGPrinter FeaturesPrint from mobile device, 6.2 kg max roll weightRAMRAM Installed (Max)1 GB / 1 GB (max)Media HandlingMedia TypePlain paper, photo paper, bond paper, recycled paper, film, glossy paperMax Media SizeA0 (841 x 1189 mm), ANSI D (559 x 864 mm), Roll (91.4 cm x 45.7 m)Min Media Size (Custom)210 mm x 279 mmMax Media Size (Custom)914 mm x 45.7 mMedia SizesA4 (210 x 297 mm), A3 (297 x 420 mm), A2 (420 x 594 mm), A1 (594 x 841 mm), A0 (841 x 1189 mm), ANSI D (559 x 864 mm), Roll (91.4 cm x 45.7 m)Media Thickness RangeUp to 0.3 mmMedia Weight60 g/m2 - 280 g/m2NetworkingNetworkingPrint serverExpansion / ConnectivityConnections1 x USB 2.0 - 4 pin USB Type B
1 x LAN - RJ-45MiscellaneousCompliant StandardsFCC Class B certified, CSA, ICES Class B, WEEE, ERPPowerPower DevicePower supply - internalVoltage RequiredAC 120/230 VFrequency Required50/60 HzPower Consumption Operational35 WattPower Consumption Stand by0.2 WattPower Consumption Sleep2.1 WattSoftware / System RequirementsSoftware IncludedHP Support Assistant, HP Click, HP DesignJet UtilityEnvironmental StandardsEPEAT CompliantEPEAT GoldENERGY STARYesManufacturer WarrantyService & SupportLimited warranty - parts - 1 yearEnvironmental ParametersMin Operating Temperature5 °CMax Operating Temperature40 °CHumidity Range Operating20 - 80%Sound Emission (Idle)16 dBASound Emission (Operating)42 dBADimensions & WeightWidth131.7 cmDepth60.5 cmHeight93.2 cmWeight34.7 kgDimensions & Weight (Shipping)Width (Shipping)147 cmDepth (Shipping)57.5 cmHeight (Shipping)59 cmWeight (Shipping)55.3 kg Technical data provided by third party. We assume no liability for errors within these data.
